Ерекшелігі
Элемент | Ерекшелігі | Ескерту |
Номиналды кернеу: | 60В | Any voltage can be customized |
Nominal Capacity: | 100А | Any capacity can be customized |
Discharge Cut-Off: | 47,5 В | |
Charge Cut-Off: | 69.3V | |
Charge Current: | 30А | Free customization service |
Cont. Discharge: | 100А | Free customization service |
Peak Discharge: | 200А | Free customization service |
Импеданс: | ≤200мΩ | |
Charge Temperature: | 0℃ - 45℃ | |
Discharge Temperature: | -20℃ - 60℃ | |
Charge Method: | CC / CV | |
Life Cycle: | 6000 times | 80% DOD, Max. 100% DOD |
BMS: | With BMS | |
Өлшем: | Flexible | Any dimension can be customized |
Салмақ: | 120KG |
Мүмкіндіктер
- More than 6000 Cycles
• Battery modules available for parallel and series for higher voltage and capacity
• BMS Passive cell balance function
• IP66, IP67, water proof, dust proof, Temperature monitoring
• Customization for Size and Discharge and charge rate
• Free of Maintenance, contains no poisonous material
• No leakage, no hazardous chemistry
• Quick delivery
• Lighter in weight, smaller in size to save space.
• Powerful to increase robust operation for your marine boat or RV
• Fast charging and high power discharge rate available
• No need to add water nor worry about maintenance.
• We offer 5 years regular warranty and it can be extended up to 10 years.
Кіріктірілген BMS
Элемент | Content | Criterion |
Over charge Protection | Over charge detection voltage | 3.6~4.25V |
Over charge detection delay time | 0.1 S ~ 6S | |
Over charge release voltage | 3.5~4.25V | |
Over discharge protection | Over discharge detection voltage | 2.0~3.3V |
Over discharge detection delay time | 0.1 S ~ 6S | |
Over discharge release voltage | 2.1~3.4V | |
Зарядтау Ағымдағы қорғаныс | Charge Over current detection current | 1~100A |
Charge Over current detection delay time | 0.02S~ 6S | |
Шығару Over current protection | Discharge Over current detection current | 1~600A |
Discharge Over current detection delay time | 0.02S~ 6S | |
Қысқа protection | Short protection detection delay time | 100 u S |
Detection condition | B+ P-0.2 Omh | |
restore | Cut off load | |
Interior Resistance | Main loop electrify resistance | 2 OMh(50A) |
Current consumption | Current consume in normal operation | 1.5mA Type |
Current consumption | Current consume in sleep operation | 2 uA Type |
Note BMS is customizable. More advanced functions available, such as Bluetooth, RS485, CAN, Autocratically Heating functions, High temperature shut off, Low temperature shut off, BMS protocol available etc. Contact us for more details!
LIFEPO4 | Өлшемдері | Салмақ | with BMS | RS485/Bluetooth | Cycles | Кепілдік |
60V 10AH | 195*165*175mm | 9.5kg | Иә | Қол жетімді | 6000times | 5 жыл |
60V 20AH | 330*175*220mm | 19 кг | Иә | Қол жетімді | 6000times | 5 жыл |
60V 30AH | 407*175*235mm | 25 кг | Иә | Қол жетімді | 6000times | 5 жыл |
60V 40AH | 407*175*235mm | 28 кг | Иә | Қол жетімді | 6000times | 5 жыл |
60V 50AH | 525*240*215mm | 44kg | Иә | Қол жетімді | 6000times | 5 жыл |
60V 120AH | 420*360*550mm | 84kg | Иә | Қол жетімді | 6000times | 5 жыл |
60V 200AH | 1000*600*182mm | 156kg | Иә | Қол жетімді | 6000times | 5 жыл |
Self-heated Function (Optional)
To relieve winter range anxiety in some freezing environment, the BMS can bring with
self heating function. Resistance heating rapidly warms the inside of battery.
Start heating temperature:≤0°C. Stop heating temperature:≥10°C.
Can improve battery charge / discharge performance.
Қолдану
Біздің зауыт
ALL IN ONE is a lithium battery Manufacturer for over 15 years, recognized by customers from
Australia,Europe and North America.We offer Top quality with very good price for lithium lifepo4 batteries!
Жиі қойылатын сұрақтар
1.Q: Do you support a sample order?
A: Yes, welcome to order sample, we have warehouses in the United States and Europe, some samples can be quickly shipped.
2.Q: Does the product have a built-in BMS?
A: Yes, intelligent BMS including JBD/PACE/SmarTec built-in to ensure batteries are under smartly managed.
3.Q: Can your company accept customized order ?
A: Of course, customization is our strength.
4.Q: Can the battery pack be compatible with the inverters on the market?
A: Yes sir, our packs are compatible with more than 20 inverter brands on the market including Victron, Goodwe, Solis, Growatts, Voltronics, Deye and other famous brands.
5.Q: How is the Warranty?
A: 5 years upto its usage.
6.Q: Do you have any certifications?
A: CE, UN38.3 and MSDS, Pack UL1973 is under processing.
7.Q: How's the delivery way and time?
A: 30-50 days for customized order. Monthly production capacity 6x40HQ for standard models.
8.Q: Do you have real factory?
A: Yes, our factory is in Anhui. We welcome you to visit our factory.
