Ерекшелігі
Тауар атауы | БАРЛЫҒЫ БІРЕУІНДЕ |
Модель | AIN7260 |
Кепілдік | 5 жыл |
Номиналды кернеу | 76,8 В |
Номиналды сыйымдылық | [email protected]/customize |
Энергетика | 4416Wh |
Ішкі қарсылық | ≤50мΩ |
Циклдік өмір | 4000 Cycles @ 0.2C Charging/Discharging ,Until 80% Capacity |
Өздігінен ағызу | ≤ айына 3,5% 25 at |
Максималды зарядтау кернеуі | 87.6 V |
Зарядтау режимі | At 0℃~45℃ temperature, charged to 87.6 V at a constant current of 0.2C, and then,changed continuously with constant voltage of 87.6 V until the current was not more than 0.02C |
Зарядтау тогы | 30А |
Максималды зарядтау тогы | 60А |
Зарядсыздандыру тогы | 30А |
Max. discharge Continuous Current | 60А |
Импульстік ток | 120A(<3S) |
Өшіру кернеуі | 60В |
Зарядтау температурасы | 0 ℃ - 45 ℃ (32 ℉ - 113 ℉) @ 60 ± 25% салыстырмалы ылғалдылық |
Шығару температурасы | -20 ℃-ден 60 ℃ (-4 140 ден 140 ℉) @ 60 ± 25% салыстырмалы ылғалдылық |
Сақтау температурасы | 0 ℃ - 45 ℃ (32 ℉ - 113 ℉) @ 60 ± 25% салыстырмалы ылғалдылық |
Су шаңына төзімділік | IP55 |
Ұяшық және формат | LFP 60AH 24S1P/customize |
Корпус | Metal Case |
Өлшем (L * W * H * TH) | теңшеу |
Салмақ | 50kg |
Терминал | M6 or Anderson or another bolt screw |
Peak discharge current BMS | 60А |
High temp port. Low temp port. | over charge port. over discharge port. |
Зарядтау әдісі | CC / CV |
Terminal Type | M6 or Anderson or another bolt screw/customize |
Сертификат | CE, RoHS ,MSDS and UN38.3 certification |
applications | Golf Carts, Electric Forklifts,Slow Speed Car; AGV,Electric Motorcycle; Sightseeing car;RV ,Tricycle, electric vehicles, Electric Wheelchairs, Electric Power Systems, Uninterruptible Power Supplies, Solar Energy Storage Systems,BOATS |
Ескерту
1.Support customization, according to the specifications required by customers: voltage, capacity, power, working current, size,weight.
2. Factory wholesale price, our factory has a price advantage. Cells of the same level are the cheapest, and you can choose the corresponding cells to make a battery pack according to your requirements.
3.Before placing Order please contact customer service to communicate the required specifications to confirm the price.
Қолдану
Біздің зауыт
Why to choose us?
* We have our own factory and company, which belong to an absolute integration of industry and trade.
* A large number of batteries are in stock.
* Have very good product resources.
* Good product quality and favorable price.
* The product is 100% original and brand new.
* 100% on time delivery. Fast delivery.(including battery pack <7 days).
* Long warranty 2-5 years.
* provide sample 2-7 days.
* Professional after-sales service.
* We have a complete industrial chain and professional engineers can make battery packs that satisfy you as quickly as
possible.
If you want to know more about the information, please free feel to contact me. Thanks!
Орау және жеткізу
Қаптама
1). Carton Size: customized or based on actual weight and volume, best quality.
2). 5-layers exporting carton or customized outer packaging for paper bags;
Жүк тасу
1). By Express (3-30working days),there are express shipping or economic shipping,suitable for small quantity.
2). By Train(25-28days),for EU Country,including customs clearance, all the import tax fees and UPS delivery to the door.
3). By Sea (15-30 days), it suitable for regular mass production.
We cooperate with excellent international freight forwarding companies to provide cheap and efficient logistics services. If you have any shipping issues, please feel free to contact me.
Жиі қойылатын сұрақтар
С: Мен қалай төлеуім керек? Сіз қандай төлем түрлерін қабылдайсыз?
A: T/T, PayPal, Western Union.
Q: Үлгіге тапсырыс беруге бола ма?
Ж: Иә, аккумуляторлардың көпшілігі үшін сапаны сынауға арналған тапсырыстар ақылға қонымды және қолайлы.
Q: Is your battery quality approved?
A: Yes, we guarantee that all cells are 100% original from Brand. And we will have full inspection of each cells and grouping them before assembling into battery packs. And all finished battery packs will be under a full inspection
before shipment.
Q: How can you prove that your cells are 100% original?
A: We can show you the original pack list and other related documents.
Q: what is your lead time if I placed an order?
A: For all products in stock, our lead time is within 2 working days after payment received. For these that we don't stock for the moment such as customized battery packs, the lead time is around 7-10 days.
С: Сіздің кепілдігіңіз қандай?
A: These situations not provide return nor refund:
1.After the assembly or assembly process happen any problem, such as the protection board connected to the wrong wire burned lead to battery damage, charger failure, the assembly error or unbalanced assembly, etc.
2. Батареяның толуы/дәнекерлеу сияқты зақымдану үшін, қорғаныссыз BMS зарядтаудан туындаған батареялар жинағы.
